Industrial & Speciality Lubricants
GEAR OIL
90EP
This gear oil is formulated for use in a wide range of gear units with normal, bevel and helical gear designs, including synchromesh manual gearboxes, transmissions and axles under moderately severe load and pressure conditions. It’s benefits include excellent thermal & chemical stability and protection against rust & corrosion, ensuring longer trouble free operation.
Recommended For:
These oils meet the requirements of several automotive manufacturers for cars, vans, commercial vehicles and for industrial purposes.
Specifications:
> API GL4
> BIS 1118-92 RA 2011 (EP TYPE-GL4)
> US MIL-L-2105
Available Packs:
500 ml/1 L/5 L/7.5 L/10 L/20 L/26 L/50 L/210 L
It is a specially formulated for use in a wide range of gears which include synchromesh manual gears, transmissions and axles working under moderate to severe load and pressure conditions.
Recommended For:
These oils meet the requirements of several automotive manufacturers for cars, vans, commercial vehicles and for industrial purposes.
Specifications:
> API GL4
> BIS 1118-92 RA 2011 (EP TYPE-GL4)
> US MIL-L-2105
Available Packs:
500 ml/1 L/5 L/7.5 L/10 L/20 L/26 L/50 L/210 L
GEAR OIL
140 EP
TRANSMISSION OIL
TQ MDX
Provides outstanding resistance to oil breakdown and deposits, even under severs duty and high temperatures. Help to wear; extend transmission life and is compatible with conventional ATFs.
Recommended For:
All automatic transmission and power steering system of automobiles and earth moving machinery. Suitable for all weather conditions.
Specifications:
> ESW-M2C-33F specification of Ford Motor Co., USA
> Performances level TYPE-A, Saffix-A, Dexron 1
Available Packs:
500 ml/1 L/5 L/7.5 L/10 L/20 L/26 L/50 L/210 L
INSOL Hydraulic Oils are premium quality anti- wear type lubricants formulated with superior quality of hydro treated base stock. They provide long service life and are recommended for hydraulic and circulation systems of wide variety of equipments. These oils are also used for compressor crank case lubrication, but are not recommended for lubrication of turbines and equipments having silvercoated components.
Specifications:
> These oils pass Vickers V-1O4C vane pump test and meet IS:
> US Military MIL-L-2104B, E-DL 2/ E-PL 2, IS: 13656:2002
Available Packs:
5 L/7.5 L/10 L/20 L/26 L/50 L/210 L
HYDRAULIC OIL
HYD 32/46/68/220/320/460
REFRIGERATION OIL
FRIZ 68/32
Insol Friz oils possess high fluidity at very low temperature, resist deposit formation and have reduced tendency to foam. These oils ensure high condenser efficiency and reduced compressor valve maintenance due to fewer deposits.
Recommended For:
Friz oils are recommended for a wide range of refrigeration compressors using all conventional refrigerants (CFCs) except sulphur dioxide and are suitable for both reciprocating as well as rotary compressors.
Specifications:
> These oils meet
> IS: 4578-1989 specification.
> Insol Friz 68 also meets Carrier Corporation, U.S.A. specification
> PP 46-1
Available Packs:
7.5 L/10 L/20 L/26 L/50 L/210 L
TRANSFORMER OIL
It is a high quality un-inhibited insulating oil developed for the use in electrical transformers & circuit breakers. It is manufactured through special refining process selecting optimum types of hydrocarbons so that finished transformer oil provides longer service life. It does not contain Poly-Chlorinated Biphenyis (PCBs).
Recommended For:
It is recommended for use in all types of oil filled transformers such as in applications of power generation, transmission & distribution. It can also be used in both large substations or small pole mounted transformers. It is suitable for use in circuit breakers, switches and any other oil immersed electrical equipment..
Specifications:
INSOL Transformer Oil imeets the requirements od IS 335-1993 of un-inhibited transformer oil. INSOL Transformer Oil has been evaluated & certified by Central Power Research Institute (CPRI), Muradnagar.
Available Packs:
7.5 L/10 L/20 L/26 L/50 L/210 L
INSOL Thermic Oils have been specially developed for use as heat transfer medium in industrial application. These oils possess high viscosity index, excellent thermal and oxidation stability, low volatility and low vapour pressure to give long service life in well designed heat transfer systems. INSOL Thermic Special is recommended for well designed heat transfer system operating upto 315⁰C.
Recommended For:
It is recommended as a fluid medium in various types of heat transfer system for indirect or secondary heating in industry. The use of these oils provide rapid heating and greater flexibility.
Available Packs:
7.5 L/10 L/20 L/26 L/50 L/210 L
THERMIC OIL
RUST PREVENTIVE OIL
INSOL Rust Preventive oil is very efficient, low viscosity, solvent based, rust prevention oil for protection of both ferrous & non-ferrous metals (especially Aluminium & Zinc). It provides excellent protection from corrosion in areas of high temperatures and humidity. Our product contains VCI chemicals which work in contact phase as well as in the vapour phase and protect components by its dual action.
Recommended For:
Machined Steel Components, Aluminum components, Castings & Forgings.
Available Packs:
210 L Barrel
Physical, Chemical & Corrosion Prevention Properties
Physical Properties |
Test Method |
135-A |
|---|---|---|
| Viscosity@cSt @400C | ASTM D 445 | 2-3 Cst |
| Specific Gravity | ASTM D 1298 | 0.78-0.86 |
| Dry FilmThickness | IS 2074 | I micron |
| Flash Point (before application) | ASTM D 92 | 65C |
| Flash Point (after application) | ASTM D 92 | 220C |
| Volatiles by % (by weight) | 80% | |
| Coverage (sq m/Lt) | <200 | |
| Pour Point | ASTM D 97 | Below -50C |
| Saponification Value (mg KOH/gm) | ASTM D 94 | 5.0-7.0 |
| Water Displacement Test | Passes | |
| Degreasability | Passes |
Corrosion Prevention Properties
| Salt Spray | ASTM B 117 | <24 Hours |
| Humidity Chamber Test | ASTM D 1748 | 480 Hours |
| Indoor Protection Life(covered) | 2 Months | 2 Months |
| Indoor Protection Life(Packed) | 1 Year | 2 Year |
